1499 #8 COMB DRL/CTSK
Drill Bit; 5/16″ Dia. × 6″ OAL × 3/4″ Shank Dia. ; 60 Degrees ; 2 FL ; HSS ; Uncoated ; Series 1499
| Style | Plain Type | Coating | Uncoated |
| Drill Bit Size / Cutting Diameter (DC) | 5/16″ | Cutting Edge Material | HSS |
| Drill Bit Size / Cutting Diameter (DC) - Inch | 5/16″ | Size | #8 |
| Decimal Equivalent | 0.75″ | Point Diameter (PDD) | 5/16″ |
| Point Angle (SIG) | 60 Degrees | Measurement Type | Inch |
| Angle | 60 Degrees | Length Group | Long |
| Flute Count (NOF) | 2 | Tool Type | Combination Drill & Counter Sink |
| Overall Length (OAL) | 6″ | Series/List # | 1499 |
| Connection Diameter Machine Side (DCONMS) | 3/4″ |
Product Features
| Remarks | •Combined Drills and Countersinks •Often called center drills •Designed for drilling center holes in the ends of work pieces to be held between standard 60Deg centers. •Long Plain Type | Country of Origin | France |
Shipping Info
Additional Fees and Notes
0
Package Length
4.75000
Package Width
.75000
Package Height
.75000
Package Weight
0.6
